Solar Power Charge Controller Use For Solar Electric Fence Energizer, 10 Amp 12V/24V PWM Negative Ground
- Model
- HPSS-CONTROLLER
Item specifics
- Defense grade
- IP30
- Size
- 53.4*68.6*22.0mm
- Current system
- 3A/5A/10A
Review
Description
- Features
- parameter
- video
- download
- Product Composition
- Installation details
- Various Models
Solar Charge Controller
The preparation of the conducting wire: calculate the length of the wire, and then figure out the installation place. Before connecting the battery firstly, please pay attention to the anode and the cathode to avoid inverse connection. If reversed, the controller indicator indicates an abnormality and may damage the internal components of the controller. If correctly connected, POWER indiator will light.
Features
- Defense grade: IP30
- Size: 53.4*68.6*22.0mm
- Install the line no.:AWG22 ~ 14/2MM²
Parameter
Video
Product Installation Video
The preparation of the conducting wire: calculate the length of the wire, and then figure out the installation place. Before connecting the battery firstly, please pay attention to the anode and the cathode to avoid inverse connection. If reversed, the controller indicator indicates an abnormality and may damage the internal components of the controller. If correctly connected, POWER indiator will light.
Download
 |
HPSFENCE CATALOGUE
|
|||
Product Composition
|
LED
|
STATE
|
FUNCTION
|
|
CHAGE
|
OFF
|
Did't answer the solar panels or night
|
|
CHAGE
|
LIGHE ON
|
Battery charging status
|
|
CHAGE
|
GREEN LIGHT ON
|
Battery power is normal
|
BATTERY | RED LIGHT ON | Battery power is low |
BATTERY | BLINKING RED LAMP | Battery power shortage |
POWER | OFF | The output protection or relating to state where the off |
POWER | LIGHE ON | The controller output is normal |
Installation Details
