Model
HPS480

Item specifics

Warranty
2 years
Output energy
4.8J
Power source
12V

Product review

Description

  • Features
  • parameter
  • video
  • download
  • Product Composition
  • Installation details
  • Various Models
Electric Fence Energizer
Electric fence energizer takes in electrical energy from an outside source (either a 110V~240V outlet or a battery) and then pushes the energy out through the fence in very brief pulses. When an animal touches the energized wires, the resulting shock deters the animal from challenging the fence again.
HPS offer 0.5J/1J/2J/3.5J/4.8J(AC/AC&DC/SOLAR).

Features

  • Waterproof (IPX6)
  • Pulse indictor
  • High voltage circuit protection
  • Simple and quick to install
  • CE&ROHS certification
  • 2 year warranty
Parameter
  • Item No:HPS480
  • Longest distance:45km
  • Output energy:4.8J
  • Input voltage:12v
  • Output voltage:9000v ± 10%
  • Dimensions: 147mm x 23mm x 74mm
  • Certification: TUV/CE/IPX6
  • FOB port Shanghai / Ningbo
  • Terms of payment: T/T
Video
Product Installation Video
The HPS Fence's electric fence energizer is for containment of sheep, poultry, the exclusion of wild predators and special applications. A fence energizer takes in electrical energy from an outside source (either a 110V outlet or a battery) and then pushes the energy out through the fence in very brief pulses.
Download
HPSFENCE CATALOGUE
HPSFENCE ENERGIZER USER MANUAL


Product Composition

  • 1 1x Energizer
  • 21x Adapter
  • 31x Battery wires with large crocodile clips
  • 41x Earth connection cable with alligator clip
  • 51x Earth Stake
Installation Details
Comparison Of Various Models
Item
Max. voltage
Voltage at 500 Ohm
Stored voltage
Impulse energy max.
HPS050
12.5KV
2.5KV
0.5J
0.375J
HPS100
12.5KV
3KV
1J
0.75J
HPS200
12.5KV
4KV
2J
1.5J
HPS350
12.5KV
5.5KV
3.5J
3.6J-3.84J
HPS480
12.5KV
5.6KV
4.8J
4.8J-5.12J

Item
Earth stake
Crocodile clip
Battery12V
12A LEAD-ACID
AdapterAC-
DC/110-240V
Solar panel
10w 12v MC-SI
Outside box
HPS050/100/200
HPSA050/100/200
HPSS050/100/200
HPS350/480
